COLIBRI II Combined Flight Recorder, GPS and vario

This has to be one of the most brilliant flight recorders yet devised as not only is it ultra small and light (approx 90 gms) but it has an internal battery too, although it can be powered from the glider.

Image on the left is about 90% life size.

Principal Features:

• Weight 90 gm incl built in battery and GPS antenna
• Size 40 x 62 x 22 mm
• Approx 10 hours operation from internal battery
• 3 hours (approx) for recharge from USB port of a PC
• Sunshine readable colour display
• Integral GPS antenna – can be mounted vertically or horizontally
• Vario with audio (pilot selectable knots; feet, M/S)
• Thermal assistant function
• SD card
• No need to fly with SD card inserted; it can download flights to SD card after use
• NMEA “out” capability
• Engine Noise Level sensor built in
• Pre-set altitude warning
• Capacity for 500 TPs (See You .CUP format
• Data exchange with other current LX navigation units (suitable cables are not included)
• Basic navigation functions:
  • North indicator
  • Distance to and bearing to selected TP
  • Ground speed
  • Track being achieved
  • Wind calculation

Price for initial batch with non-IGC approval (only a few left)
Price: £200.00 excl VAT; £240.00 incl VAT Buy now!
Delivery cost will be added: UK and Europe £7.00 incl VAT; Outside Europe £12 no VAT
(this price includes shipment to and back from the factory for IGC diamond level upgrade should you require the upgrade option)

Colibri II Upgrade of initial batch to High Level IGC
Price £195.00 excl VAT; £234.00 incl VAT - Call to Buy

Colibri II with IGC diamond level approval
Price £440.00 excl VAT; £528.00 incl VAT (available from mid-December 2011)
Buy now! Delivery cost will be added: UK and Europe £7.00 incl VAT; Outside Europe £12 no VAT

Supplied with:

• Handbook
• USB to USB Mini cable
• Charger
• SD card (and adapter)

Options

• Mounting bracket (snap-in connection)
  £12.50 excl VAT: £15.00 incl VAT - Call to Buy
• DC to DC power converter (for supply from aircraft electrics)
  £17.50 excl VAT; £21.00 incl VAT - Call to Buy

So you can buy knowing that your total price for Colibri II now + Upgrade later will be less that the eventual price for a Colibri II with IGC diamond level approval, supplied new !

Nano - created by LX Nav

Nano has high level IGC approval

Manufacturer's description

The Nano flight recorder is the smallest flight recorder designed to meet the highest level IGC specification. Nano has high level IGC approval. It features an integrated 66-channel GPS receiver with built-in antenna. The built-in battery allows up to 15 hours of stand-alone operation. Bluetooth is used for easy data exchange with a PDA. Five LEDs display the operational status. A 2 Gb SD card is used for flight data storage. Flights are stored directly in IGC format and are downloadable through USB connection. The battery is charged when the flight recorder is connected to a computer.

Supplied with: Micro SD card, Mini-USB cable; and 110 – 220V USB Wall Charger, quick guide and calibration

Price: £391.67 excl VAT; £470.00 incl VAT - Buy now!
Delivery cost will be added: UK and Europe £7.00 incl VAT; Outside Europe £12 no VAT

PERSONAL FLIGHT RECORDER

Many pilots will find the new inexpensive pocket sized Personal Flight Recorder useful for basic flight analysis (and for OLC in many instances) but for some gliding badge claims, all record attempts and competition flights, IGC (International Gliding Commission) approved flight recorders (loggers) are normally required. Please note that some versions of Flarm have IGC approval (see Flarm section).

Under a recent change by the IGC these units can now be approved for national Silver and Gold distance badge flights (click here to see the new IGC regulations) – UK approval has been granted. Click here for the approval link

The new Personal Flight Recorder will be attractive to a wider aviation community than gliding: record your powered aircraft cross country flight, and see where you went, for example! As well as being a serious analytical tool, it is also a great fun device...........

Personal Flight Recorder

This non-IGC approved Personal Flight Recorder is aimed at those pilots, and not just glider pilots, who would like to have a playback facility to analyse their flights. With a size of only 70mm x 37mm x 24 mm (measure this image!) and weighing under 50 gms the Personal Flight Recorder fits easily in the pocket. Easy to use with just an on-off switch and powered by 2x internal batteries (AAA size or NiMH rechargeable equivalent) the Recorder uses a low-cost consumer GPS logging device and records GPS position and altitude. Integral GPS antenna. One year warranty is included.

100 hours recording time!



Flight playback is against a Google Earth background and shows the track flown in an easy to read format. With IGC analysis software more information can be extracted.

Click these images to view a larger version. The barograph trace opens full screen.



Supplied as follows:

•Personal Flight Recorder
•USB Cable
•CD-ROM with flywithCE Logbook, User's Manual and drivers
•2 x AAA NiMH (1000mAh) and USB charger or equivalent
•Free delivery within UK

Compare this product with similar ones:

Differences:

• Removable batteries mean that you need not be caught out by a flat battery as with a unit with integral power
• Interface software is by FlywithCE – no reliance on third party; updates free of charge
• outputs IGC format
  • IGC declaration
  • proper IGC file
• IGC file format files can be used for OLC (this status is still not 100%)
• output to Google Earth
  • 3D view
  • Barograph view (using GPS altitude and LXe or SeeYou)
  • off-line it offers more (you do not have to be connected to check the flights)
• logbook software functionality
  • browse flights by pilot, aircraft, flight time,…

Basically, the Personal Flight Recorder behaves as an IGC flight recorder in that it produces an IGC file with flight declaration. Other known devices and software are not believed to currently produce this output.

The Personal Flight Recorder and the software supplied with it gives the user a powerful piece of equipment for flight documentation and analysis.

Priced delivered in UK at: £83.29 excl VAT: £99.95 incl VAT - Buy now!

(overseas orders add delivery cost)

The FlywithCE Personal Flight Recorder is approved by the BGA as a Position Recorder for Silver and Gold Badge Flights only.

Operating Tips

Click here for brochure and more information

New Colibri – F   Flight Recorder

Colibri with Flarm

The smallest Flight Recorder with a display with high level IGC approval (pending)

Now with both SD card and Flarm

Overview

Colibri is small in size but big in functionality. When used as a stand-alone unit it can be used for real time navigation, wind calculation and logging engine status; when connected to another system it can be used to supply a GPS signal.

This latest upgrade of Colibri by the addition of Flarm makes the unit potentially an even more popular flight recorder to add to the 1000s already in use worldwide. A 100% Flarm compatible electronic system has been built into the already diminutive Colibri housing. The Flarm antenna connector is positioned on the top of the unit and permits either a ¼ wave antenna or an extended antenna to be connected. The standard Flarm external display is also part of the delivery and is connected via a USB form of connector. All existing IGC and navigation functions remain unchanged and, in addition, the built in Flarm flight recorder (not IGC approved) provides a back up.

Please note that the mini usb port of the Colibri Flarm is used solely for the Flarm display and update function and not for routine flight downloads etc.

All you need to claim badges, records or competition flights; and now with Flarm

Features:

• Integral Flarm
• SD memory card (can be used to transfer flights, TP/TSK data and flight info)
• Membrane keyboard
• Multi Pilot/Glider set up
• IIf connected to a LX 160/LX 1600 and SeeUMobile/FlywithCE/Win Pilot or LX 7000 without GPS the Colibri becomes part of an advanced Flight System
• High Level IGC approval (pending as at Feb 07) makes the Colibri the ideal IGC Flight Recorder to claim your badge, record and competition flights.

Technical Specification
Firmware version:	5
Memory	75 hours @ 12 s recording interval (automatic overwrite)
Database	600 Turning Points 100 tasks 4500 airfields
Engine noise level	Yes; standard
Dimensions	59 x 35 x 98 mm
Weight	200 g

PRICE £860.00 excl VAT; £1032.00 including VAT
Only one left - product discontinued - Call to Buy

Please ask for price with Graphic Display in lieu of standard display

Supplied with short rod antenna, as illustrated. If you want a dipole or lamda/4 antenna then please add this to the above prices. (Sorry, but we can no longer offer credit for short rod antenna).

Colibri v4 Flight Recorder

With USB port for communication and power.

SD card included.



Smallest IGC approved flight recorder, with a display, on the market.

Ideal GPS source for a LX 1606, LX 166, etc.



• Extremely small; only 60mm x 97mm x 35mm, weight 230g
• High level IGC approval
• Flight recorder and basic navigation functions
• Memory to store 100 tasks, 600 turning points and approx 4000 airports
• NMEA output compatible with SeeYou Mobile, Navigator and Winpilot
• Thousands in use
• When connected to PC USB port it will exchange data and receive power from PC
•Supplied with cable set, mains power supply adaptor, mounting, antenna, LXe program and Handbook. (in fact you will probably not need all the combinations of cable that are supplied !)

Price Further Reduced from the previous £699.00 incl VAT:

Run-out sale (as available)

Price: £360.00 excl VAT; £432.00 incl VAT Buy now!
Delivery cost will be added: UK and Europe £7.00 incl VAT; Outside Europe £12 no VAT



Note. All Colibri IGC flight data recorders supplied directly to our customers by LX avionics Ltd are pre-loaded with BGA TPs free of charge.
